XCON System Decomposition Conference System Floor Control Client TEMPLATE Of the SYSTEM: Pre-configured Initial/Default values Conf Event Notification Server Focus Call Signaling Client TEMPLATE Policy: RESERVATION Policy: CURRENT Policy: RESERVATION Of the INSTANCE: STATE Of the CURRENT INSTANCE: Notification Client Floor Control Server SIP/ PSTN/ H.323 T.120/ Etc. SIP NOTIFY/ Etc. BFCP Client Updated Logical names. Corrected “directionality”. Added logical grouping of data Conference-Object Data Manipulation Server Data Manipulation Client |
